REVIEW ARTICLE


Direct At-Sea Observations of Elephant Seals (Mirounga spp.) to Help Interpret Digital Bio-logging Data



John van den Hoff1, *, Sam Thalmann2
1 Australian Antarctic Division, 203 Channel Highway, Kingston, 7050, Tasmania, Australia
2 Department of Primary Industries, Parks, Water and Environment, GPO Box 44, Hobart, 7001, Tasmania, Australia


© 2020 John & Sam

open-access license: This is an open access article distributed under the terms of the Creative Commons Attribution 4.0 International Public License (CC-BY 4.0), a copy of which is available at: https://creativecommons.org/licenses/by/4.0/legalcode. This license permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

* Address correspondence to this author at: Australian Antarctic Division, 203 Channel Highway, Kingston, 7050, Tasmania, Australia; Email: john_van@aad.gov.au


Abstract

Background:

A key short-fall with animal-borne bio-logging instruments, which collect digital time-series data regarding the foraging behaviours of cryptic marine mammal species, is validating those data against in situ behaviours.

Objective:

To collate direct observations of elephant seal feeding behaviour to help interpret foraging behaviours inferred from Time-Depth Recorder (TDR) data.

Methods:

Direct observations of elephant seal foraging behaviour were collated from the published literature using a search of the world-wide-web. Those observations were supplemented with an unpublished record.

Results:

Two deep-sea video recordings and six surface sightings of elephant seals ingesting prey were collated. Each observation either supported or suggested an alternative to behaviours derived from digital time-depth profiles. The tendency for elephant seals to surface following the capture of large prey suggests precipitous drops in stomach temperature at the sea-surface, which have been recorded and interpreted as drinking events, more likely represent the ingestion of large prey items.

Conclusion:

Direct observations of marine mammal foraging behaviours are rare, yet they provide a means to continuously evaluate and interpret outcomes of bio-logging instruments.

Keywords: Bio-logging, Foraging behaviour, Marine mammal, Stomach temperature, Time-depth recorder, Elephant seals (Mirounga spp.).



1. INTRODUCTION

One way to gather information about highly mobile and migratory species, such as marine mammals, is through the use of bio-logging instruments which, depending on the array of sensors deployed, record aspects of an individuals’ movements and behaviours at set time intervals [1]. However, historical bio-logging studies often lack complementary deployments (e.g. video recorder + TDR), which combine to provide a more comprehensive picture for foraging behaviours that are beyond the boundary of our visibility or experiences [2, 3]. Nevertheless, knowledge of animal migration patterns and foraging behaviours inform us of when, where and how the Earths’ biota interacts with its environment and also with human resource requirements.

Elephant seals (Mirounga spp.) are large-bodied migratory marine mammals. All age classes have been tracked by satellite telemetry to remote oceanic or continental settings where attached bio-logging instruments have recorded several different functional dive types, including foraging dives where the seals are purported to prey on the suite of benthic and pelagic species during what have been termed “wiggles” in the dive profiles (Fig. 1) [4-7]. Compared with females, male elephant seals are up to 10 times larger and differ in their foraging ecology by preferentially hunting for benthic prey over continental shelves whereas females forage in more open pelagic waters [4]. The cumulative effects of their lengthy temporal migrations to geographically remote locations combined with the near-continuous diving behaviour for both sexes and all age classes [8] makes direct observations of elephant seals a novelty.

Here, we collated direct observations of foraging behaviour for Mirounga spp. We supplement those records with an unpublished image of a male M. leonina ingesting prey at the sea-surface. Our objective is to discuss those results with respect to dive behaviours that have been inferred from two-dimensional data collected using digital TDRs and stomach temperature sensors.

Fig. (1). Schematic representations of: A. Typical two-dimensional (time-depth) dive profiles recorded by free-ranging elephant seals (Mirounga spp.) during periods of travel (transit), rest/digestion (drift) and feeding. Benthic (bottom) dive profiles are constrained by depth and therefore have flat-bottom phases compared with mid-water (pelagic) dive profiles. Feeding dives contain a number of brief excursions between depths. B. Within dive behaviours of southern elephant seals (M. leonina) during type Eb benthic foraging dives known as “wiggles” (Source: Sala et al. 2011). Note the orientation of the seal during the bottom phase of the dive profile is consistent with that observed directly (van den Hoff et al. (2017). C. Changes in stomach temperature with swim speed and depth during Type D dives. The precipitous drop in stomach temperature recorded at the sea-surface has been suggested as indicative of surface seawater drinking (Source: Horsburgh et al. (2007).

2. METHODS

Reports of direct observations of elephant seal feeding were collated through an internet search using “video footage elephant seal feeding” and “surface feeding elephant seal” as the search terms. Two direct video recordings of elephant seals feeding at extreme depths were found. Two published accounts of elephant seals feeding at the sea-surface were found and those supplemented with a third unpublished observation.

3. RESULTS AND DISCUSSION

3.1. Deep Water Observations

Two studies have serendipitously captured brief observations of feeding in elephant seals. The first was via a video camera anchored to the seafloor at a depth of 894 m in the Barkley Canyon, west of Vancouver Island, Canada. Footage was captured of a free-ranging northern elephant seal (M. angustirostris), of unknown sex, predating a soft-bodied hag-fish (Eptetratus sp., 25/June/2012, https://bmscblog. wordpress.com/2013/04/03/citizen-scientist-spots-a-hungry-elephant-seal-in-barkley-canyon/ (accessed 14/05/2020). No pre/post-ingestion behaviour was witnessed but the seal captured Eptetratus sp. by suction feeding and swallowed it immediately at depth.

The second study captured video footage of M. leonina attacking Patagonian toothfish (Dissostichus eleginoides) hooked on commercial longlines near Heard Island [9] (https://doi.org/10.1371/journal.pone.0172396.s004,and.s005). Although the behaviours recorded were in a somewhat artificial setting (i.e. a lit environment with tethered prey), the footage provides insights into the behaviour of the seals as they encountered benthic prey at depths in excess of 1000 m. Seals swam close to the sea-floor and undertook brief (meters) excursions from the seafloor as they circled hook-caught fish of ~ 1 m in length. Prey capture behaviour included a “head-down” orientation and a turn toward the surface following seizure of the prey item.

3.2. Surface Observations

Three adult male M. angustirostris have been observed consuming large-bodied elasmobranchs such as stingrays (Urolophus halleri), blue sharks (Prionace glauca) and spiny dogfish (Squalus acanthis) head-first at the seas-surface [10]. There was one report of a male M. leonina feeding at the sea-surface on what was believed to be a large fish, perhaps a D. eleginoides, that was presumed captured in about 1000 m of water to the northwest of South Georgia (53º39' S, 38º24' W) [11].

Here, we supplement the record for M. leonina with a further sighting of a sub-adult male (aged 6 - 8 y) swallowing head-first a draughtboard shark (Cephaloscyllium laticeps) in the near-shore surface waters (≤ 70 m) of south-east Tasmania (43º11' S, 147º58' E; Fig. 2). Combined, those five surface observations suggest large hard-bodied prey items captured at depth are bought to the sea-surface for manipulation prior to ingestion.

Fig. (2). Still image of a male southern elephant seal (Mirounga leonina) swallowing a draughtboard shark (Cephaloscyllium laticeps) head-first at the sea surface off Munroe Bight, Tasman Peninsula, Tasmania (43º 11'23” S, 147º 58'24” E) on the 30th March 2008. The water depth was ~ 70 m. Photo courtesy of the Department of Primary Industries, Parks, Water and Environment (Tasmania).

3.3. Informing TDR Derived Behaviours

What is currently (2020) known of adult male Mirounga foraging behaviours is outweighed by what is known for adult females and juveniles, and for that reason, some male behaviours have been assumed from other age/sex classes. But, behaviours inferred from single-sensor TDR deployments do not always equate with those derived from complementary multi-sensor studies, nor might they be applied across species or even between age classes within species [12-15]. This makes the observations described here valuable for understanding specific foraging behaviours of adult male Mirounga spp.

The behaviours of male M. leonina captured directly by video camera [9] conformed well to behaviours inferred from TDR records. For example, there were small excursions from the seafloor that are characteristic of “wiggle” type anomalies commonly seen in elephant seal feeding dive profiles (Fig. 1A). The head-down orientation observed by video just prior to prey capture has also been digitally recorded and termed “up-ending” in the benthos (Fig. 1B), [16]. It was also clear from the video that not all wiggles and head-down orientations were prey capture attempts, some were searching activities. More- over, up-ending events seem to equate more closely to prey capture attempts than wiggles in feeding dives, confirming the usefulness of complementary sensor deployments.

Observations of Mirounga spp. feeding on large prey items at the sea-surface offer an alternative explanation for the precipitous drops in stomach temperature that have been termed “drinking events” (Fig. 1C), [17]. Practically speaking, stomach temperature telemetry uses measured changes in a predators’ core body temperature to imply consumption of ectothermic prey and/or the ingestion of water [18]. Changes in stomach temperature for one free-ranging female M. angustirostris, whose dive behaviour appeared to be unconstrained by bathymetry, occurred during the bottom phases of putative type D pelagic foraging dives (Fig. 1C) [19]. Feeding was inferred from anomalies in stomach temperature that were associated with increased swim velocity and wiggles (Fig. 1C), and importantly an upward movement through the water column to shallower depths [17]. Unlike other studies [18, 19], Horsburgh and others [17] recorded decreases in stomach temperature at the sea-surface which they assigned to drinking events (Fig. 1C). However, deliberate drinking of seawater in pinnipeds seems equivocal. Harbor seals (Phoca vitulina), for example, did not drink seawater voluntarily [20] but a captive leopard seal (Hydrurga leptonyx) drank large quantities of seawater when placed in the ocean [21].

All Mirounga spp. observed feeding at the surface were manipulating large, hard-bodied, deep-dwelling benthic prey species ([10, 11,] this study) which can reach at least 1.5 m in length [22]. Since the ingestion of large prey causes a rapid decrease in stomach temperature [18], we consider the stomach temperature changes that recorded at the sea-surface by Horsburgh et al. [17] as evidence for the ingestion of large prey. If it is a requirement for Mirounga ssp. to surface to manipulate large prey items prior to ingestion, it follows that anomalously long intervals between dives in the TDR records (known as extended surface intervals [8]) could indicate successful capture of large prey items.

CONCLUSION

Direct observations of feeding by free-ranging, near-continuous deep-diving marine mammals are extremely rare. However, they provide a valuable means for identifying behaviours that will aid in interpreting underwater behaviours digitally recorded with the use of bio-logging instruments [23]. Without verification, the risk of subjectivity and preconceived notions of inferred behaviour will continue, but assigning behavioural activities to digital data remains a challenge [24]. For that reason, continually re-evaluating TDR data free from predilection and by all means available will refine species prey consumption model estimates. Moreover, humans can more completely appreciate the degree to which marine predators overlap with their own requirements for marine resources.

AUTHORS’ CONTRIBUTIONS

JvdH conceived the paper, collated the data and wrote the manuscript.

ST shared the image of a male southern elephant seal feeding in southern Tasmania and contributed to manuscript preparation.

Both authors read and approved the final manuscript.

CONSENT FOR PUBLICATION

Not applicable

FUNDING

Not applicable

CONFLICT OF INTEREST

The authors declare no conflicts of interest, financial or otherwise.

ACKNOWLEDGEMENTS

We thank the reviewers for their constructive comments. The Australian Antarctic divisions’ Dan Broun drew Figs. (1A and 1C).

REFERENCES

[1] Fehlmann G, King AJ. Bio-logging. Curr Biol 2016; 26(18): R830-1.
[2] Boyd IL, Kato A, Ropert-Coudert Y. Bio-logging science: Sensing beyond the boundaries. Mem Natl Inst Polar Res Spec Issue 2004; 58: 1-14.
[3] Ramirez-Llodra E, Tyler PA, Baker MC, et al. Man and the last great wilderness: Human impact on the deep sea. PLoS One 2011; 6(8)e22588
[4] Hindell MA, McMahon CR, Bester MN, et al. Circumpolar habitat use in the southern elephant seal: implications for foraging success and population trajectories. Ecosphere 2016; 7(5): e01213.
[5] Saijo D, Mitani Y, Abe T, et al. Linking mesopelagic prey abundance and distribution to the foraging behaviour of a deep-diving predator, the northern elephant seal. Deep Sea Res II: Topical Studies in Oceanography 2017; 140: 163-170.
[6] Hindell MA. Encyclopedia of marine mammals 2018; 303-7.
[7] Labrousse S, Williams G, Tamura T, et al. Coastal polynyas: Winter oases for subadult southern elephant seals in East Antarctica. Sci Rep 2018; 8(1): 3183.
[8] Hindell MA, Slip DJ, Burton HR. The diving behavior of adult male and female southern elephant seals, Mirounga leonina (Pinnipedia, Phocidae). Aust J Zool 1991; 39: 595-619.
[9] van den Hoff J, Kilpatrick R, Welsford D. Southern elephant seals (Mirounga leonina Linn.) depredate toothfish longlines in the midnight zone. PLoS One 2017; 12(2): e0172396.
[10] Condit R, LeBoeuf BJ. Feeding habits and feeding grounds of the northern elephant seal. J Mammal 1984; 65: 281-90.
[11] Reid K, Nevitt GA. Observation of southern elephant seal, Mirounga leonina, feeding at sea near South Georgia. Mar Mamm Sci 1998; 14: 637-40.
[12] Francke DL, Hargrove SA, Vetter EW, Winn CD, Balazs GH, Hyrenbach KD. Behavior of juvenile green turtles in a coastal neritic habitat: Validating time–depth–temperature records using visual observations. J Exp Mar Biol Ecol 2013; 444: 55-65.
[13] McGovern KA, Rodríguez DH, Lewis MN, Davis RW. Diving classification and behavior of free-ranging female southern elephant seals based on three-dimensional movements and video-recorded observations. Mar Ecol Prog Ser 2019; 620: 215-32.
[14] Mitani Y, Andrews RD, Sato K, Kato A, Naito Y, Costa DP. Three-dimensional resting behaviour of northern elephant seals: Drifting like a falling leaf. Biol Lett 2010; 6(2): 163-6.
[15] Volpov BL, Hoskins AJ, Battaile BC, et al. Identification of prey captures in Australian fur seals (Arctocephalus pusillus doriferus) using head-mounted accelerometers: Field validation with animal-borne video cameras. PLoS One 2015; 10(6)e0128789
[16] Sala JE, Quintana F, Wilson RP, Dignani J, Lewis MN, Campagna C. Pitching a new angle on elephant seal dive patterns. Polar Biol 2011; 34: 1197-209.
[17] Horsburgh JM, Morrice MG, Lea M-A, Hindell MA. Determining feeding events and prey encounter rates in a southern elephant seal: A method using swim speed and stomach temperature. Mar Mamm Sci 2008; 24: 207-17.
[18] Kuhn CE, Costa DP. Identifying and quantifying prey consumption using stomach temperature change in pinnipeds. J Exp Biol 2006; 209(Pt 22): 4524-32.
[19] Kuhn CE, Crocker DE, Tremblay Y, Costa DP. Time to eat: Measurements of feeding behaviour in a large marine predator, the northern elephant seal Mirounga angustirostris. J Anim Ecol 2009; 78(3): 513-23.
[20] Fisher HD, Depocas F, Hart JS. Sea water drinking and water flux in starved and in fed harbor seals, Phoca vitulina. Can J Physiol Pharmacol 1971; 49(1): 53-62.
[21] Brown KG. Observations on the newly born leopard seal. Nature 1952; 170: 982-3.
[22] Last PR, Stevens JD, Eds. Sharks and Rays of Australia 1994.
[23] Robert-Coudert Y, Wilson RP. Subjectivity in bio-logging: do logged data mislead? Mem Natl Inst Polar Res Spec Issue 2004; 58: 23-33.
[24] Carter MID, Bennett KA, Embling CB, Hosegood PJ, Russell DJ. Navigating uncertain waters: A critical review of inferring foraging behaviour from location and dive data in pinnipeds 2016; 4(25): 20.
